is our mission to provide to the oil and gas producers of the Appalachian Basin,
highly trained and knowledgeable, experienced personnel, modern and safe
equipment and a commitment to excellence in service.
Company History Profile
Timco, Inc. has been actively engaged in the
oil and gas well service industry since 1978, filling the needs for specialized
well chemicals and the trained personnel to deliver and install the chemicals in
the well. Timco further expanded services to swab rigs, service rigs and power
swivel in 1980,
hydrocarbon services in 1985 and wire line services in 1991. The same year Timco
expanded sales to the international market by selling used cable tool drilling
rigs and tools, worldwide.
Today we speclize in our Cased Hole Wireline
Services, Hydrocarbon and Chemical Services and Tools for Cable Rigs.
are the Eastern Distrubitor for the Owens Casing Patch Systems
57051 MARIETTA ROAD
BYESVILLE, OHIO 43723
TIM BROWN: FOUNDER, PRESIDENT & CEO
Tim has actively been engaged
in the oil and gas industry since 1975; has drilled, completed and maintained
hundreds of wells in and around the Appalachian Basin; founded Timco, Inc. in
1978 and continues as its President and CEO today. Feel Free to contact Tim,
his e-mail is
email@example.com or cell phone
INSTALL THE OWENS CASING PATCH SYSTEMS
Tubing Casing Patch Technologies
The Owen X-SPANŽ Tubing/Casing patch System provides a proven, durable and
dependable seal over perforations, splits, corrosions or leaks in all types of
tubulars. This system can be deployed on electric wireline or tubing and used on
conventional, horizontal, monobore, multi-lateral, slim hole or geothermal well
bores. The Owen X-SPANŽ System has proven to be an economical and reliable
solution for a broad range of applications, including shutting off unwanted
water influx, zonal protection for frac-through applications, repairing tubular
leaks from pin holes to collar leaks, repairing corroded or eroded tubing or
casing as well as isolating frac ports and auxiliary tools in horizontal wells.
The large bore assures easy passage of service tools including bridge plugs,
drop balls, seal bore assemblies, logging tools and perforating systems. The
minimal surface equipment required for deploying the patch and rig less
intervention results in tremendous savings for the operator. The metal-to-metal
X-SPANŽ seal is proven technology engineered for high temperature applications
while yielding the highest burst and collapse pressure ratings in the industry.
The X-SPANŽ casing patch can be deployed to protect 300-ft (91-m) sections of
tubing or casing on a single trip, with multi-trip stackable patches available
to span longer intervals. X-SPANŽ Systems can be designed using premium alloys
for extreme well bore environments and custom sized for most tubing
The full range of Owen's X-SPANŽ Technology include:
X-SPANŽ System consists of three basic components; a top metal to metal
sealing element, a tubular extension and a bottom metal to metal sealing
element. The system is modular and patch lengths can be adjusted at the
field. It is the most reliable patch on the market and the pressure
integrity is not reduced due to casing conditions.
GTX-SPANŽ adds premium sealing elements with each element containing two
elastomer seals that have enabled us to provide the industry with the first
effective gas tight patch.
BPX-SPANŽ is an elastomer free bridge plug designed for hostile well
conditions that can cause the elastomers to swell on standard bridge plugs
while running in the hole. The BPX-SPANŽ uses our proven metal to metal seal
technology to create a mechanical seal and anchor to the casing wall. The
BPX-SPANŽ can include a ceramic knock out sub, pump out sub or burst disc or
be converted as a hanger system for velocity strings or include a tailpipe
assembly with profile subs.
The new multi-trip stackable
STX-SPANŽ version can be utilized to isolate longer intervals and
deployment can be performed on flowing or static wells. The STX-SPANŽ System
is also ideal for wells with limited rig up height and on wells that have
severe dog legs where only short sections will pass. Each section seals to
the previous one via a ratchet latch stinger and seal bore receptacle.
SST-SPANŽ is an elastomer free suspension or hanger tool that can be
used to hang tubing or velocity strings in a well. The SST-SPANŽ uses our
proven metal to metal seal technology to create a mechanical seal and anchor
to the casing wall. The SST-SPANŽ is well suited for hostile environments
including high C02 and high temperature applications.
All Owen X-SPANŽ Systems are easily deployed using a range of multi-stage
explosive or hydraulic setting tools. The explosive setting tools can be
initiated electrically, on e-line or slick line using a variety of compatible
firing systems. For your conventional tubing or coil tubing deployment
requirements, we have several sizes of hydraulically operated setting tools
available. X-SPANŽ Systems are easily removable by just milling off the sealing
elements. The reliability and quality of the X-SPANŽ System has been proven many
times over the past several years with over 2900 installations completed with a
success rate of 98% when setting depth has been achieved.
The Owen Oil Tools Tubing/Casing Patch uses multi-dimensional metal-to-metal
X-SPANŽ Technology to provide a permanent seal over perforations and to stop
leaks of all types.
OWENS patches can be run in any type of well including horizontal, multilateral,
slim hole, monobore, or geothermal. X-SPANŽ Technology is economical and
reliable when used for water shut off or zonal isolation applications. The large
bore assures easy passage of Magna Range bridge plugs, logging tools, coiled
tubing tools, and perforating systems.
Water shut-off / zonal isolation
Seals leaking liner tops
Suspension of gravel pack screens
Large ID PBRs
